| Parameter |
Value |
| Number of print-heads |
1 |
| Print height |
from 1.5 to 14 mm |
| Distance between print-head and object |
from 1 to 30 mm |
| Print-head position during the printing |
any |
| Print-head dimensions |
diameter: Ø 40 mm, length: 163 mm |
| Length of print-head cable |
4 m (optionally up to 8 m) |
| Ink types |
coloured homogeneous non-pigment inks, provided that ink of one type only is used |
| Character size (matrices) |
5x5, 7x5, 9x5, 9x7, 11x8, 12x6, 12x7, 14x9, 16x10, 16x14, 21x15, 25x15, 32x18 and others |
| National characters |
multilingual diacritical characters (also Polish characters), the Cyrillic alphabet, Arabic characters, Japanese characters (katakana and a set of kanji characters), Chinese or Korean characters |
| Number of lines |
up to 4 for the 7x5-dot matrix |
| Graphics |
graphics of any length and a height of up to 32 dots to be inserted at any point of a text to be printed (a built-in graphics processor) |
| Special graphics characters |
a set of pre-programmed graphics characters of frequent use, in the form of 7, 16 and 25-dot fonts - see >>> |
| Bar codes |
Datalogic, Matrix, 2/5 5 Bars, Interleaved, Alpha 39, EAN-8, EAN-13, Code 128, EAN-128, Code 128B, ITF8, ITF14.
All bar codes can be printed in inversion a preset number of times and supplemented by numerical label and the width of stripes can be adjusted after ink changes its consistency. |
| Two-dimensional (2D) code |
Data Matrix ECC-200 |
| Maximum print rate for Speed=FAST |
1488 cps for 7x5 matrix*),
334 cps for 16x10 matrix *).
*) plus 1-row space between characters |
| Maximum print rate for Speed=SLOW |
372 cps for 7x5 matrix*),
88 cps for 16x10 matrix*),
55 cps for 25x14 matrix*),
32 cps for 32x18 matrix*). |
| Timing |
an internal generator whose timing frequency is defined with appropriate print parameters,
an external sensor of conveyor travel rate, a shaft-encoder, |
| Detector of objects to be labelled |
a photo-detector as standard,
other detectors can be connected, if required by a user |
| Terminal |
a built-in graphics terminal equipped with an alphanumerical keyboard and LCD graphics display as standard,
a multilingual user interface also including the Japanese, Chinese or Korean languages |
| Control and operation with the use of an external IBM-compatible PC (optional and independent on the built-in terminal) |
 to control the operation of one printer via the program EdGraf and either an RS-232C interface for cables up to 10 m long as standard, with the option of automatic negotiation of the transmission rate of 9600 Bd or 19200 Bd, or an RS-485 interface for longer connections,
to control a network of interconnected EBS printers of various types via the program InkNet and an RS-485 interface; transmission rate of 19200 B |
| Additional serial port to connect external devices such as scales, bar code readers, computers and others |
V24/RS232 or TTL, the maximum transmission rate of 19200 Bd |
| Operating conditions |
|
| Power supply |
input rating:
AC 87-242V at 45-440Hz, DC 90-350V;
current:
0,5 - 0,27 A for standard version |
| Compressed air supply |
 not required !!! |
| Environment |
operating temperature:
from +5°C to +40°C as standard,
from -10°C for special versions;
relative humidity:
up to 90% noncondensing |
| Acceptable exposure to vibration and impacts |
vibration:
up to 1g at the maximum of 10Hz;
impacts:
up to 1g for the maximum of 2 ms |
| Dimensions |
height: 435 mm,
width: 300 mm,
depth: 202 mm,
width when the ink system door is open: 382 mm,
length (depth) when the ink system door is open: 410 mm |
| Weight |
approximately 12.9 kg without ink or solvent bottles |
| Required inactive time |
none; the device can run uninterruptedly for 24 hours |
| Ink systems |
to be filled with homogenous non-pigment inks, equipped with an ink pressure pump and a separate vacuum pump,
does not require any compressed air supply |
